Picture In Picture | Android Studio | Java

How to add Picture In Picture Mode in the android app?

The Android 8.0 (API level 26) allows activities to launch in the picture-in-picture (PIP) mode. PIP is a special type of multi-window mode mostly used for video playback. It lets the user watch a video in a small window pinned to a corner of the screen while navigating between apps or browsing content on the main screen. The PIP window appears in the top layer of the screen in a corner chosen by the system.

>>Check For Kotlin

Video:

Step 1: Create a new project OR Open your project

Step 2: Create another activity named PIPActivity

Step 3: Add the following properties to the PIPActivity in AndroidManifest

<activity android:name=".PIPActivity"
            android:configChanges="screenSize|smallestScreenSize|screenLayout|orientation"
            android:launchMode="singleTask"
            android:resizeableActivity="true"
            android:supportsPictureInPicture="true"/>

Step 3: Code

AndroidMenifest.xml

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.blogspot.atifsoftwares.pictureinpicture">

    <!-- internet permission -->
    <uses-permission android:name="android.permission.INTERNET" />

    <application
        android:allowBackup="true"
        android:icon="@mipmap/ic_launcher"
        android:label="@string/app_name"
        android:roundIcon="@mipmap/ic_launcher_round"
        android:supportsRtl="true"
        android:theme="@style/Theme.PictureInPicture">

        <activity android:name=".PIPActivity"
            android:configChanges="screenSize|smallestScreenSize|screenLayout|orientation"
            android:launchMode="singleTask"
            android:resizeableActivity="true"
            android:supportsPictureInPicture="true"/>

        <activity android:name=".MainActivity">
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>

</manifest>

actiivty_main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:padding="20dp"
    android:orientation="vertical"
    android:gravity="center"
    tools:context=".MainActivity">

    <!--Button click, play 1st video-->
    <Button
        android:id="@+id/videoOneBtn"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:text="Video One"/>

    <!--Button click, play 2nd video-->
    <Button
        android:id="@+id/videoTwoBtn"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:text="Video Two"/>

    <!--Button click, play 3rd video-->
    <Button
        android:id="@+id/videoThreeBtn"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:text="Video Three"/>

</LinearLayout>

MainActivity.java

package com.blogspot.atifsoftwares.pictureinpicture;

import androidx.appcompat.app.AppCompatActivity;

import android.content.Intent;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;

public class MainActivity extends AppCompatActivity {

    //video urls/links
    private static final String videoUrlOne = "https://commondatastorage.googleapis.com/gtv-videos-bucket/sample/BigBuckBunny.mp4";
    private static final String videoUrlTwo = "https://commondatastorage.googleapis.com/gtv-videos-bucket/sample/WeAreGoingOnBullrun.mp4";
    private static final String videoUrlThree = "https://commondatastorage.googleapis.com/gtv-videos-bucket/sample/VolkswagenGTIReview.mp4";

    private Button videoOneBtn, videoTwoBtn, videoThreeBtn;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        //init UI Views
        videoOneBtn = findViewById(R.id.videoOneBtn);
        videoTwoBtn = findViewById(R.id.videoTwoBtn);
        videoThreeBtn = findViewById(R.id.videoThreeBtn);


        //handle clicks, to play specific video in new activity
        videoOneBtn.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                playVideo(videoUrlOne);
            }
        });
        videoTwoBtn.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                playVideo(videoUrlTwo);
            }
        });
        videoThreeBtn.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                playVideo(videoUrlThree);
            }
        });
    }

    private void playVideo(String videoUrl){
        //Intent to start acitivity, with video url
        Intent intent = new Intent(MainActivity.this, PIPActivity.class);
        intent.putExtra("videoURL", videoUrl);
        startActivity(intent);
    }
}

activity_pip.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="#000"
    tools:context=".PIPActivity">

    <!--VideoView: Play Video-->
    <VideoView
        android:id="@+id/videoView"
        android:layout_width="match_parent"
        android:layout_centerInParent="true"
        android:layout_height="wrap_content"/>

    <!--ImageButton: Click to switch to Picture In Picture Mode-->
    <ImageButton
        android:id="@+id/pipBtn"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:src="@drawable/ic_pip_white"
        android:layout_alignParentEnd="true"
        android:background="@android:color/transparent"
        android:layout_margin="10dp"/>

</RelativeLayout>

PIPActivity.java

package com.blogspot.atifsoftwares.pictureinpicture;

import androidx.appcompat.app.ActionBar;
import androidx.appcompat.app.AppCompatActivity;

import android.app.PictureInPictureParams;
import android.content.Intent;
import android.content.res.Configuration;
import android.media.MediaPlayer;
import android.net.Uri;
import android.os.Build;
import android.os.Bundle;
import android.util.Log;
import android.util.Rational;
import android.view.View;
import android.widget.ImageButton;
import android.widget.MediaController;
import android.widget.VideoView;

public class PIPActivity extends AppCompatActivity {

    private Uri videoUri;
    private static final String TAG = "PIP_TAG";

    private VideoView videoView;
    private ImageButton pipBtn;

    private ActionBar actionBar;

    private PictureInPictureParams.Builder pictureInPictureParams;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_p_i_p);

        //actionbar
        actionBar = getSupportActionBar();

        //init UI Views
        videoView = findViewById(R.id.videoView);
        pipBtn = findViewById(R.id.pipBtn);
        setVideoView(getIntent());//get and pass intent to a method that will handle video playback, intent contains url of video

        //init PictureInPictureParams, requires Android O and higher
        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.O){
            pictureInPictureParams = new PictureInPictureParams.Builder();
        }

        //handle click, enter PIP mode
        pipBtn.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                pictureInPictureMode();
            }
        });

    }

    private void setVideoView(Intent intent) {
        String videoURL = intent.getStringExtra("videoURL");
        Log.d(TAG, "setVideoView: URL:"+ videoURL);

        //MediaController for play, pause, seekbar, time etc
        MediaController mediaController = new MediaController(this);
        mediaController.setAnchorView(videoView);

        videoUri = Uri.parse(videoURL);

        //set media controller to videoview
        videoView.setMediaController(mediaController);
        //set video uri to videoview
        videoView.setVideoURI(videoUri);

        //add video prepare listener
        videoView.setOnPreparedListener(new MediaPlayer.OnPreparedListener() {
            @Override
            public void onPrepared(MediaPlayer mp) {
                //when video is ready, play it
                Log.d(TAG, "onPrepared: Video Prepared, Playing...");
                mp.start();
            }
        });
    }

    private void pictureInPictureMode(){
        //Requires Android O and higher
        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.O){
            Log.d(TAG, "pictureInPictureMode: Supports PIP");

            //setup height and width of PIP window
            Rational aspectRation = new Rational(videoView.getWidth(), videoView.getHeight());
            pictureInPictureParams.setAspectRatio(aspectRation).build();
            enterPictureInPictureMode(pictureInPictureParams.build());
        }
        else {
            Log.d(TAG, "pictureInPictureMode: Doesn't supports PIP");
        }
    }

    @Override
    protected void onUserLeaveHint() {
        super.onUserLeaveHint();
        //called when user presses Home button, enter in PIP mode, requires Android N
        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.N){
            if (!isInPictureInPictureMode()){
                Log.d(TAG, "onUserLeaveHint: was not in PIP");
                pictureInPictureMode();
            }
            else {
                Log.d(TAG, "onUserLeaveHint: Already in PIP");
            }
        }
    }

    @Override
    public void onPictureInPictureModeChanged(boolean isInPictureInPictureMode, Configuration newConfig) {
        super.onPictureInPictureModeChanged(isInPictureInPictureMode, newConfig);
        if (isInPictureInPictureMode){
            Log.d(TAG, "onPictureInPictureModeChanged: Entered PIP");
            //hide Pip button and actionbar
            pipBtn.setVisibility(View.GONE);
            actionBar.hide();
        }
        else {
            Log.d(TAG, "onPictureInPictureModeChanged: Exited PIP");
            //show pip button and actionbar
            pipBtn.setVisibility(View.VISIBLE);
            actionBar.show();
        }
    }

    @Override
    protected void onNewIntent(Intent intent) {
        super.onNewIntent(intent);
        //when video 1 is playing in PIP mode, and user clicks video 2: handle/play new video
        Log.d(TAG, "onNewIntent: Play new Video");
        setVideoView(intent);
    }

    @Override
    protected void onStop() {
        super.onStop();
        if (videoView.isPlaying()){
            videoView.stopPlayback();
        }
    }
}

Step 4: Run Project
